TECHNICAL DETAILS:
• Sensor: 1/3 SONY color
• Video System: CVBS PAL
• Total pixels: PAL 1312 (H) x 993 (V) High Resolution
• Horiz. resolution: 780TV Lines
• Wide Dynamic Range (WDR)
• Lens: F2.0 2.9mm
• View angle: 140° diagonal / 112° horizontal / 84° vertical
• 5 IR-LEDs nightvision (8-10M) (build-in day/night sensor)
• Image view: Normal / Mirror (adjustable)
• Power voltage : DC12V [9-30V]
• Power consumption: 150mA IR ON, 80mA IR OFF
• Operation temperature : -30°C tot +85°C
• Size: 57(D)*69(W)*42(H) mm
• Connector: 4p mini-DIN (CarVision definition)
• Weight: 350g
• IP classification: IP69K
• Microphone: yes
• (E11) 10R-0611428
